1ggte gen3 clutch size

[cresslux]

Hi Guys,

have done a lot of soarching and cant find the exact answer im looking for.

i am putting a w55 behind a 1g-gze and i have a gen3 1ggte flywheel.

i had an old 7m-ge/2jz-ge clutch lying around and the friction plate is the correct size, but the pressure plate is slightly too big (by around 10mm)

i had been told LN106 (or any 3L or 5L clutch) has the right size pressure plate, is this correct?

[masterofsinanju]

Here is what I put in my 1ggze 6 months back. Pretty sure I got these numbers off another toymods post. Do some more google fu, there's a fair bit of stuff on the forums.

CLUTCH
Bellhousing – 1G
Clutch Fork – 1G
Flywheel - 1G (240mm contact face - Gen. 3 only)

Clutch Kit
1.EXEDY TYK-6878 Standard 236mm x 29.8 Spline OD x 21 Teeth
Includes
Cover Assembly TYC574,
Clutch Disc TYD113U and
Release Bearing BRG2217
2.EXEDY SPORTS TUFF TYK-6878HD Heavy Duty
3.Spigot Bearing 6001

[cresslux]

thanks, just wanted to make sure before i fork out for a clutch.

i have everything else already.

[hypo23]

i have the clutch and pressure plate on the left for sale, in the below pic if you interested let me know.

Even the one on the right could be for sale very shortly with a record w58 box attached too let me know if you interested.

Both are far better than the off the shelf excedy options.

[hypo23]

The one on left does this.

[SillyCarS]

Hypo.. will it suit my gen 3 1ggte. if you can do $200 posted to brissy consider it sold

[hypo23]

Clutch face is 225mm so apparently suit gen 1 or 2
